1015SD Single Stage Rotary Vane Vacuum Pump

$2,825.00
SKU:
PF115SDMLAM
Pumping Speed:
16.5 m³/h | 275 l/min | 9.7 cfm
Final Pressure (without ballast):
5 hPa | 75 Torr | 5 mbar
Final Pressure (with ballast):
7 hPa | 25 Torr | 5 mbar
Intake Pressure (Max):
100 hPa | 75 Torr | 100 mbar
Exhaust Pressure (Max):
5 × 10³ hPa | 1125 Torr | 1.5 × 10³ mbar
Operating Fluid:
Mineral Oil
Operating Fluid Capacity:
1 liter
Inlet/Outlet Flange:
NW25
Motor Type:
DC motor
Input Voltage:
90–132 VAC, 50/60 Hz (±10%)
Nominal Rotation Speed:
1800 rpm
Sound Pressure Level:
56 dB(A)
Cooling Method:
Natural convection
Operating Altitude (Max):
2000 m
Dimensions (L × W × H):
442 × 164 × 225.5 mm | 17.40 × 6.46 × 8.88 in
Weight:
5 kg | 11.02 lb
Protection Degree:
IP43
Certification:
cTUVus (UL / CSA 61010-1)
Ambient Temperature Range:
12–40 °C | 6–104 °F
Storage/Shipping Temperature:
5–65 °C | 14–140 °F
Mains Cable:
US
Number of Pumping Stages:
Single stage
Gas Ballast:
Available as accessory
Adding to cart… category.add_cart_announcement

Product Description

The 1015SD is a compact, high-performance single stage rotary vane vacuum pump designed for reliability across a wide range of scientific, industrial, and instrumentation applications. Featuring a direct drive motor, anti-suckback system, and foldaway handle, it delivers stable operation and easy handling. Its vertical sight glass simplifies oil monitoring, while its standardized NW25 flanges make it compatible with a variety of vacuum accessories.

Features

  • Single stage rotary vane design with direct drive motor
  • Electrically insulated foldaway handle for easy portability
  • Anti-suckback system maintains vacuum integrity during shutdowns
  • Vertical sight glass for clear oil level inspection
  • Natural convection cooling for quiet, efficient operation
  • Standardized NW25 inlet and outlet flanges for accessory compatibility
  • Gas ballast option supports pumping of condensable vapors
  • Engineered for ease of maintenance and long-term performance

Applications

The 1015SD vacuum pump is ideal for a wide variety of uses, including:

  • Research and development labs
  • Freeze-drying and pharmaceutical processing
  • Mass spectrometry and electron microscopy
  • Semiconductor manufacturing and leak detection systems
  • General industrial drying, refrigeration, and chemical processing

All prices are in US$. Website pricing is good only for the USA. Please call for International pricing.

Resources

https://cdn11.bigcommerce.com/s-fsqecafu8p/product_images/uploaded_images/user-manual-thumbnails.png?t=1630510154

Product Videos

Custom Field

Pumping Speed 16.5 m³/h | 275 l/min | 9.7 cfm
Final Pressure (without ballast) 5 hPa | 75 Torr | 5 mbar
Final Pressure (with ballast) 7 hPa | 25 Torr | 5 mbar
Intake Pressure (Max) 100 hPa | 75 Torr | 100 mbar
Exhaust Pressure (Max) 5 × 10³ hPa | 1125 Torr | 1.5 × 10³ mbar
Operating Fluid Mineral Oil
Operating Fluid Capacity 1 liter
Inlet/Outlet Flange NW25
Motor Type DC motor
Input Voltage 90–132 VAC, 50/60 Hz (±10%)
Nominal Rotation Speed 1800 rpm
Sound Pressure Level 56 dB(A)
Cooling Method Natural convection
Operating Altitude (Max) 2000 m
Dimensions (L × W × H) 442 × 164 × 225.5 mm | 17.40 × 6.46 × 8.88 in
Weight 5 kg | 11.02 lb
Protection Degree IP43
Certification cTUVus (UL / CSA 61010-1)
Ambient Temperature Range 12–40 °C | 6–104 °F
Storage/Shipping Temperature 5–65 °C | 14–140 °F
Mains Cable US
Number of Pumping Stages Single stage
Gas Ballast Available as accessory
