Product Description
COREVAX's 3.5 CFM Professional Pump Package features a rugged W2V10 rotary vane vacuum pump - a dual-stage, oil-sealed design producing 3.5 CFM and an ultimate vacuum of 10-3 Torr or 29.9 inHG. This pump is lightweight, quiet, compact and features an anti-suckback valve and gas ballast knob, quick disconnect ISO/KF25 fittings, and is ideal for a variety of applications.
Key Features
-
- W2V10 3.5 CFM two-stage oil-sealed vacuum pump with 120V/220V 60 Hz motor
- Dual-stage NW 25 exhaust / oil mist eliminator with coalescing media cartridges for the oil mist and adsorptive activated carbon cartridge to remove any residual vapors or odors
- Digital display Pirani vacuum gauge module with power cable for 120V, range 760 Torr to 10-3 Torr with NW 25 adaptor tee for easy installation at pump inlet or at system inlet
- 4.5" clear vacuum trap with stainless steel gauze cartridge and NW 25 inlet and outlet ports
- NW 25 clamps and centering rings for installation of provided accessories
- 1 set of replacement cartridges for inlet trap and exhaust filters
- 1 gallon of VacOil 19 grade vacuum pump oil
- 1 gallon of VacOil flushing fluid
Resources
Warranty
LACO warrants to the original Customer that all new goods furnished by Seller shall be free from defect in workmanship and material at the time and place of delivery by LACO. LACO will honor claims in the event of failure of goods (other than expendable and consumable parts) as a result of such a defect, provided that a claim is made to LACO in writing within twelve months from the date of delivery.Product Videos
Custom Field
Pumping Speed @ 60 Hz 100 l/m, 3.5 cfm, 6 m3/hour
Pumping Speed @ 50 Hz 83 l/m, 3 cfm, 5 m3/hour
Ultimate Pressure (Gas Ballast Open) 5 x 10-2 Torr
Ultimate Pressure (Gas Ballast Closed) 1 x 10-3 Torr
Standard Motor, CE Marked 15V, 1 HP, 60 Hz, On/Off Switch
Power Connection 6 ft (2 m) 3 conductor cord
Motor Speed @ 60 Hz 1700 rpm
Oil Capacity 500 cc (.53 quart)
Intake/Exhaust type/diameter NW 25 (26 mm) O.D. tube
Ambient Operating Temperature 7 to 40 °C (45 to 104 °F)
Dimensions 15.67" x 5.91" x 9.88" (L x W x H)
Weight 50.00
